TSC DH340 Desktop Label Printer (DH340-A001-1032)

Regular price 823,10 € +VAT
Power Cord
EUUK
Resolution (dpi)
203300
Wired Interfaces
USBUSB, RS232, Ethernet
Linerless
NoYes
Form Factor
2-inch desktop4-inch desktop
Display
3.5" colour touchscreenNone (LED indicators)

Free Shipping over 250 €. Usually delivered within 3–5 working days.

0% VAT for EU/EEA companies (excl. Estonia). Enter a valid VAT number to automatically generate a 0% VAT invoice.

TSC TH/DH240 Series (DH340-A001-1032)
TSC
TSC DH340 Desktop Label Printer (DH340-A001-1032)
Regular price 823,10 € +VAT

The TSC DH340 (DH340-A001-1032) is a 4-inch direct thermal desktop label printer that prints at 300 dpi and up to 152 mm/s (6 ips), with a max. print width of 105.7 mm – no ribbon needed. This LED version keeps operation simple with status icons and three buttons – ideal when little configuration is needed. It takes 127 mm (5") linerless label rolls, speaks TSPL-EZD with automatic EPL, ZPL and DPL emulation and connects via USB 2.0, RS-232, 10/100 Ethernet and a USB host port. The factory-fitted linerless cutter kit cuts linerless labels to any length – no liner waste. Supplied with power supply, power cord (EU Schuko plug) and USB cable – ready to print.

📦 What's in the box – DH340-A001-1032

  • ✅ TSC DH340 label printer – 300 dpi, 4" (105.7 mm), USB 2.0 + RS-232 + Ethernet + USB host
  • ✅ Linerless cutter kit (factory-fitted) – non-stick linerless platen roller and cutter (full cut) for linerless labels
  • ✅ Power supply – external universal power supply, 100–240 V AC → 24 V DC, 90 W
  • ✅ Power cord – EU plug (Schuko)
  • ✅ USB cable – USB 2.0 A-to-B – connect and print straight away
  • ✅ Drivers & software – Windows driver, TSC Console and labeling software – free download from TSC
  • ✅ Setup guide
  • ❌ Linerless labels – NOT included – this version prints on linerless direct thermal media only – see the compatible linerless rolls below
  • ❌ Ethernet (LAN) cable – NOT included – use any standard RJ45 patch cable

✅ Ready to print: power supply, power cord and USB cable are in the box – you only need linerless direct thermal labels (no ribbon required).

💡 Useful extras: the TSC SP-COM-0025 linerless cleaning kit to keep the non-stick platen roller and cutter free of adhesive; the TSC OP-COM-0002 external roll mount for large rolls on 3" cores; the TSC WF-TH240-2001 Wi-Fi + Bluetooth 5.0 module for wireless printing; the TSC BP-4000-0002 battery pack to run the printer without a mains socket.

Key Features

  • Direct thermal printing at 300 dpi – up to 152 mm/s (6 ips), max. print width 105.7 mm; no ribbon to buy or change
  • LED status and icon indicators with feed, pause and reprint buttons – no display to configure
  • Linerless direct thermal labels up to 120 mm wide on 25.4–38.1 mm cores (max. 127 mm OD) – no liner waste and more labels per roll
  • TSPL-EZD firmware with automatic EPL, ZPL/ZPL II and DPL language switching – existing label templates print unchanged
  • USB 2.0, RS-232, 10/100 Ethernet and USB host as standard; Wi-Fi 802.11ac + Bluetooth 5.0 or Bluetooth 5.0 modules can be added later
  • 128 MB Flash, 128 MB SDRAM, microSD slot (up to 512 GB) and real-time clock
  • Remote management via embedded web page, virtual control panel, TSC Console and SOTI Connect; HTTPS, SNMPv3 and 802.1X security
  • TPH Care printhead diagnostics and tool-free printhead and platen roller replacement
  • Factory-fitted linerless cutter kit (full cut) with non-stick platen roller
  • Eco design: 100% recyclable packaging and casing made with 30% recycled plastic; 3-year TSC warranty in EMEA

Ideal Applications

  • Quick-service restaurants and food delivery – order and takeaway labels
  • Grocery and fresh food – weigh-scale, price and date labels
  • Retail – price and promotion labels without liner waste
  • Transport and logistics – shipping labels with less waste

All DH Series Versions

The highlighted row is the version you are currently viewing.

Part Number Model Print Width Resolution Display Media Option Interfaces Power Cord
DH220-A001-0002 DH220T 2" (54 mm) 203 dpi 3.5" touch LCD Tear-off USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH220-A001-1002 DH220 2" (54 mm) 203 dpi LED (no display) Tear-off USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH220E-A001-0002 DH220E 2" (54 mm) 203 dpi LED (no display) Tear-off USB only EU (Schuko) View product
DH220E-A001-0003 DH220E 2" (54 mm) 203 dpi LED (no display) Tear-off USB only UK View product
DH320-A001-0002 DH320T 2" (56.9 mm) 300 dpi 3.5" touch LCD Tear-off USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH320-A001-1002 DH320 2" (56.9 mm) 300 dpi LED (no display) Tear-off USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH320E-A001-0002 DH320E 2" (56.9 mm) 300 dpi LED (no display) Tear-off USB only EU (Schuko) View product
DH320E-A001-0003 DH320E 2" (56.9 mm) 300 dpi LED (no display) Tear-off USB only UK View product
DH240-A001-0002 DH240T 4" (108 mm) 203 dpi 3.5" touch LCD Tear-off USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH240-A001-0032 DH240T 4" (108 mm) 203 dpi 3.5" touch LCD Linerless (cutter) USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH240-A001-1002 DH240 4" (108 mm) 203 dpi LED (no display) Tear-off USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH240-A001-1012 DH240 4" (108 mm) 203 dpi LED (no display) Peeler USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH240-A001-1022 DH240 4" (108 mm) 203 dpi LED (no display) Cutter USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH240-A001-1032 DH240 4" (108 mm) 203 dpi LED (no display) Linerless (cutter) USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH240-A001-1042 DH240 4" (108 mm) 203 dpi LED (no display) Linerless (tear-off) USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH340-A001-0002 DH340T 4" (105.7 mm) 300 dpi 3.5" touch LCD Tear-off USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH340-A001-1002 DH340 4" (105.7 mm) 300 dpi LED (no display) Tear-off USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH340-A001-1012 DH340 4" (105.7 mm) 300 dpi LED (no display) Peeler USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH340-A001-1022 DH340 4" (105.7 mm) 300 dpi LED (no display) Cutter USB, RS-232, Ethernet, USB host EU (Schuko) View product
DH340-A001-1032 (this version) DH340 4" (105.7 mm) 300 dpi LED (no display) Linerless (cutter) USB, RS-232, Ethernet, USB host EU (Schuko) Viewing
DH340-A001-1042 DH340 4" (105.7 mm) 300 dpi LED (no display) Linerless (tear-off) USB, RS-232, Ethernet, USB host EU (Schuko) View product

Technical Specifications

Part Number DH340-A001-1032
Model TSC DH340 (DH Series, 4-inch)
Printer Type 4-inch desktop direct thermal label printer
Print Method Direct thermal
Resolution 300 dpi (12 dots/mm)
Print Speed Up to 152 mm/s (6 ips)
Max Print Width 105.7 mm (4.16")
Max Print Length 11,430 mm (450")
Media Width 15–120 mm (0.59"–4.72"); 10 mm with the optional narrow media adaptor
Media Thickness 0.06–0.19 mm (2.36–7.48 mil)
Roll Diameter 127 mm (5") OD
Core Size 25.4–38.1 mm (1"–1.5")
Media Types Linerless direct thermal labels (outside wound); label length 5 mm – 11,430 mm
Sensors Transmissive gap sensor, reflective black-mark sensor (position adjustable), head-open sensor
Ribbon Not required – direct thermal printing
Interfaces USB 2.0, RS-232 serial, internal Ethernet 10/100 Mbps, USB host; microSD card slot
Wireless None as standard – optional Wi-Fi 802.11a/b/g/n/ac + Bluetooth 5.0 combo module or Bluetooth 5.0 module
Processor 32-bit RISC CPU
Memory 128 MB Flash, 128 MB SDRAM; microSD expansion up to 512 GB (FAT32/exFAT)
Real-Time Clock Standard
Printer Languages TSPL-EZD with automatic EPL, ZPL, ZPL II and DPL language switching
Fonts / Character Sets 8 alphanumeric bitmap fonts; Monotype true-type engine with CG Triumvirate Bold Condensed; ARIALUNI.TTF Unicode font (UTF-8); 0/90/180/270° rotation
Barcodes 1D: Code 39, Code 93, Code 128 (UCC, subsets A/B/C), Codabar, Interleaved 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN/UPC add-on, MSI, Plessey, Postnet, China Post, ITF-14, EAN-14, Code 11, Telepen, Planet, Code 49, Deutsche Post Identcode/Leitcode, LOGMARS; 2D: TLC39, Codablock F, PDF417, MicroPDF417, MaxiCode, DataMatrix, QR Code, Aztec, GS1 DataBar
Display No display – LED status and icon indicators; power, feed, pause and reprint buttons
Media Options Linerless cutter kit: non-stick linerless platen roller and cutter, full cut (factory-fitted)
Options Peel-off module, guillotine cutter, linerless tear-off kit, linerless cutter kit, Wi-Fi + Bluetooth 5.0 combo module, Bluetooth 5.0 module, MFi Bluetooth 5.0 (factory option), external label roll mount, KP-200 Plus keyboard, 10 mm narrow media adaptor, BP-4000 battery pack
Management & Security Internal embedded web page, virtual control panel, TSC Console, SOTI Connect (licence); HTTPS, SNMPv3, 802.1X, TCP/IP port 9100 filter; TPH Care printhead diagnostics
Power Supply External universal switching power supply: 100–240 V AC, 2.0 A, 50–60 Hz input; 24 V DC, 3.75 A, 90 W output
Dimensions (W × D × H) 208 × 235 × 170 mm (W × D × H)
Weight 2.1 kg
Color Black
Operating Temperature 0–40 °C, 25–85% RH non-condensing
Storage Temperature −40–60 °C, 10–90% RH non-condensing
Certifications CB, FCC Class B, IC, cTÜVus, NOM, CE Class B, UKCA, EAC, CCC, BIS, RCM, KC, ENERGY STAR 3.0; RoHS, REACH, WEEE
Warranty Printer: 3 years (TSC EMEA, purchases from 1 June 2024); printhead 25 km or 12 months, platen 50 km or 12 months (whichever comes first)
In the Box TSC DH340 printer (300 dpi, LED indicators, no display, USB 2.0 + RS-232 + Ethernet + USB host, factory-fitted linerless cutter kit (linerless platen roller + cutter)), external power supply (24 V DC, 90 W), power cord (EU Schuko plug), USB cable, quick start guide – linerless labels NOT included (direct thermal, no ribbon needed)

Need a different width, resolution, display or media option? All DH Series versions are listed above. Compare other models in our Desktop Label Printers collection or contact our team for volume pricing.
