TSC DH220E 2-inch desktop direct thermal label printer, 203 dpi, USB, LED, black (DH220E-A001-0002) – front view

TSC DH220E 2-inch desktop direct thermal label printer, 203 dpi, USB, LED, black (DH220E-A001-0002) – angled view

TSC DH220E 2-inch desktop direct thermal label printer, 203 dpi, USB, LED, black (DH220E-A001-0002) – detail view

TH DH Series: The Handy Way to Conquer Label Printing Challenges

TH DH Series: Seamless Integration with Effortless Deployment

TSC DH220E Desktop Label Printer (DH220E-A001-0002)

Name: TSC DH220E Desktop Label Printer (DH220E-A001-0002)
Brand: TSC
SKU: tsc220
Availability: InStock

241,61 € +VAT

Product variants

Power Cord

EUUK

Resolution (dpi)

203300

Wired Interfaces

USBUSB, RS232, Ethernet

Linerless

NoYes

Series

Cutter Peeler / dispenserTear-off

Form Factor

2-inch desktop4-inch desktop

Memory

—RAM: 128 MB, Flash: 128 MBRAM: 16 MB, Flash: 8 MB

Display

3.5" colour touchscreenNone (LED indicators)

Free Shipping over 250 €. Usually delivered within 3–5 working days.

0% VAT for EU/EEA companies (excl. Estonia). Enter a valid VAT number to automatically generate a 0% VAT invoice.

Available: In Stock
Vendor: TSC
Type: Desktop Printers
Barcode: DH220E-A001-0002
Collections: Desktop Label Printers , Label Printers , Shipping Label Printers

📄 Download Product Brochure (PDF)

TSC

TSC DH220E Desktop Label Printer (DH220E-A001-0002)

241,61 € +VAT

Description

Description

The TSC DH220E (DH220E-A001-0002) is the entry model of the TSC DH Series: a compact 2-inch direct thermal desktop label printer that prints at 203 dpi and up to 203 mm/s (8 ips), with a max. print width of 54 mm – no ribbon needed. It keeps things simple with LED status indicators, a single USB 2.0 port and 16 MB SDRAM / 8 MB Flash, takes 127 mm (5") label rolls and understands TSPL-EZD with EPL, ZPL and DPL emulation – ideal for one workstation printing barcode, product and address labels. Supplied with power supply, power cord (EU Schuko plug) and USB cable – ready to print.

📦 What's in the box – DH220E-A001-0002

✅ TSC DH220E label printer – 203 dpi, 2" (54 mm), USB 2.0
✅ Power supply – external power supply, 100–240 V AC → 24 V DC
✅ Power cord – EU plug (Schuko)
✅ USB cable – USB 2.0 A-to-B – connect and print straight away
✅ Drivers & software – Windows driver, TSC Console and labeling software – free download from TSC
✅ Setup guide
❌ Labels – NOT included – order labels to suit your application (see compatible labels below)

✅ Ready to print: power supply, power cord and USB cable are in the box – you only need direct thermal labels (no ribbon required).

💡 Useful extras: the TSC OP-COM-0002 external roll mount for large rolls on 3" cores; a spare power cord (TSC SP-COM-2001 or TSC SP-COM-3001).

Key Features

Direct thermal printing at 203 dpi – up to 203 mm/s (8 ips), max. print width 54 mm; no ribbon needed
Entry model of the DH Series: LED status indicators and buttons, no display to configure
USB 2.0 (type B) interface – plug in and print from a single PC
127 mm (5") label rolls on 25.4–38.1 mm cores, media 15–60 mm wide; continuous, die-cut and black-mark labels
TSPL-EZD with EPL, ZPL/ZPL II and DPL emulation – existing label templates print unchanged
16 MB SDRAM and 8 MB Flash for fonts, graphics and label formats; labels up to 2,286 mm (90") long
Compact clamshell design (138 × 210 × 172 mm) with easy drop-in media loading
Set up and managed with TSC Console; 3-year TSC warranty in EMEA

Ideal Applications

Small businesses and webshops – shipping and address labels
Retail – price, product and barcode labels
Offices – file, asset and archive labels
Healthcare and laboratories – simple sample and medication labels

All DH Series Versions

The highlighted row is the version you are currently viewing.

Part Number	Model	Print Width	Resolution	Display	Media Option	Interfaces	Power Cord
DH220-A001-0002	DH220T	2" (54 mm)	203 dpi	3.5" touch LCD	Tear-off	USB, RS-232, Ethernet, USB host	EU (Schuko)	View product
DH220-A001-1002	DH220	2" (54 mm)	203 dpi	LED (no display)	Tear-off	USB, RS-232, Ethernet, USB host	EU (Schuko)	View product
DH220E-A001-0002 (this version)	DH220E	2" (54 mm)	203 dpi	LED (no display)	Tear-off	USB only	EU (Schuko)	Viewing
DH220E-A001-0003	DH220E	2" (54 mm)	203 dpi	LED (no display)	Tear-off	USB only	UK	View product
DH320-A001-0002	DH320T	2" (56.9 mm)	300 dpi	3.5" touch LCD	Tear-off	USB, RS-232, Ethernet, USB host	EU (Schuko)	View product
DH320-A001-1002	DH320	2" (56.9 mm)	300 dpi	LED (no display)	Tear-off	USB, RS-232, Ethernet, USB host	EU (Schuko)	View product
DH320E-A001-0002	DH320E	2" (56.9 mm)	300 dpi	LED (no display)	Tear-off	USB only	EU (Schuko)	View product
DH320E-A001-0003	DH320E	2" (56.9 mm)	300 dpi	LED (no display)	Tear-off	USB only	UK	View product
DH240-A001-0002	DH240T	4" (108 mm)	203 dpi	3.5" touch LCD	Tear-off	USB, RS-232, Ethernet, USB host	EU (Schuko)	View product
DH240-A001-0032	DH240T	4" (108 mm)	203 dpi	3.5" touch LCD	Linerless (cutter)	USB, RS-232, Ethernet, USB host	EU (Schuko)	View product
DH240-A001-1002	DH240	4" (108 mm)	203 dpi	LED (no display)	Tear-off	USB, RS-232, Ethernet, USB host	EU (Schuko)	View product
DH240-A001-1012	DH240	4" (108 mm)	203 dpi	LED (no display)	Peeler	USB, RS-232, Ethernet, USB host	EU (Schuko)	View product
DH240-A001-1022	DH240	4" (108 mm)	203 dpi	LED (no display)	Cutter	USB, RS-232, Ethernet, USB host	EU (Schuko)	View product
DH240-A001-1032	DH240	4" (108 mm)	203 dpi	LED (no display)	Linerless (cutter)	USB, RS-232, Ethernet, USB host	EU (Schuko)	View product
DH240-A001-1042	DH240	4" (108 mm)	203 dpi	LED (no display)	Linerless (tear-off)	USB, RS-232, Ethernet, USB host	EU (Schuko)	View product
DH340-A001-0002	DH340T	4" (105.7 mm)	300 dpi	3.5" touch LCD	Tear-off	USB, RS-232, Ethernet, USB host	EU (Schuko)	View product
DH340-A001-1002	DH340	4" (105.7 mm)	300 dpi	LED (no display)	Tear-off	USB, RS-232, Ethernet, USB host	EU (Schuko)	View product
DH340-A001-1012	DH340	4" (105.7 mm)	300 dpi	LED (no display)	Peeler	USB, RS-232, Ethernet, USB host	EU (Schuko)	View product
DH340-A001-1022	DH340	4" (105.7 mm)	300 dpi	LED (no display)	Cutter	USB, RS-232, Ethernet, USB host	EU (Schuko)	View product
DH340-A001-1032	DH340	4" (105.7 mm)	300 dpi	LED (no display)	Linerless (cutter)	USB, RS-232, Ethernet, USB host	EU (Schuko)	View product
DH340-A001-1042	DH340	4" (105.7 mm)	300 dpi	LED (no display)	Linerless (tear-off)	USB, RS-232, Ethernet, USB host	EU (Schuko)	View product

Technical Specifications

Part Number	DH220E-A001-0002
Model	TSC DH220E (DH Series entry model, 2-inch)
Printer Type	2-inch desktop direct thermal label printer
Print Method	Direct thermal
Resolution	203 dpi (8 dots/mm)
Print Speed	Up to 203 mm/s (8 ips)
Max Print Width	54 mm (2.13")
Max Print Length	2,286 mm (90")
Media Width	15–60 mm (0.59"–2.36")
Roll Diameter	127 mm (5") OD
Core Size	25.4–38.1 mm (1"–1.5")
Media Types	Continuous, die-cut and black-mark labels and tags (outside wound)
Ribbon	Not required – direct thermal printing
Interfaces	USB 2.0 (type B) only – no RS-232, Ethernet or USB host
Wireless	None
Memory	16 MB SDRAM, 8 MB Flash
Printer Languages	TSPL-EZD with EPL, ZPL, ZPL II and DPL emulation
Display	No display – LED status indicators and buttons
Media Options	Tear-off
Options	10 mm narrow media adaptor, external label roll mount
Management & Security	TSC Console
Power Supply	External power supply: 100–240 V AC input, 24 V DC output
Dimensions (W × D × H)	138 × 210 × 172 mm (W × D × H)
Weight	1.3 kg
Color	Black
Operating Temperature	0–40 °C, 25–85% RH non-condensing
Warranty	Printer: 3 years (TSC EMEA, purchases from 1 June 2024); printhead 25 km or 12 months, platen 50 km or 12 months (whichever comes first)
In the Box	TSC DH220E printer (203 dpi, LED indicators, USB 2.0 only), external power supply (24 V DC), power cord (EU Schuko plug), USB cable, quick start guide – labels NOT included (direct thermal, no ribbon needed)

Need a different width, resolution, display or media option? All DH Series versions are listed above. Compare other models in our Desktop Label Printers collection or contact our team for volume pricing.
