| Part Number |
DH240-A001-0032 |
| Model |
TSC DH240T (DH Series, 4-inch) |
| Printer Type |
4-inch desktop direct thermal label printer |
| Print Method |
Direct thermal |
| Resolution |
203 dpi (8 dots/mm) |
| Print Speed |
Up to 203 mm/s (8 ips) |
| Max Print Width |
108 mm (4.25") |
| Max Print Length |
25,400 mm (1,000") |
| Media Width |
15–120 mm (0.59"–4.72"); 10 mm with the optional narrow media adaptor |
| Media Thickness |
0.06–0.19 mm (2.36–7.48 mil) |
| Roll Diameter |
127 mm (5") OD |
| Core Size |
25.4–38.1 mm (1"–1.5") |
| Media Types |
Linerless direct thermal labels (outside wound); label length 5 mm – 25,400 mm |
| Sensors |
Transmissive gap sensor, reflective black-mark sensor (position adjustable), head-open sensor |
| Ribbon |
Not required – direct thermal printing |
| Interfaces |
USB 2.0, RS-232 serial, internal Ethernet 10/100 Mbps, USB host; microSD card slot |
| Wireless |
None as standard – optional Wi-Fi 802.11a/b/g/n/ac + Bluetooth 5.0 combo module or Bluetooth 5.0 module |
| Processor |
32-bit RISC CPU |
| Memory |
128 MB Flash, 128 MB SDRAM; microSD expansion up to 512 GB (FAT32/exFAT) |
| Real-Time Clock |
Standard |
| Printer Languages |
TSPL-EZD with automatic EPL, ZPL, ZPL II and DPL language switching |
| Fonts / Character Sets |
8 alphanumeric bitmap fonts; Monotype true-type engine with CG Triumvirate Bold Condensed; ARIALUNI.TTF Unicode font (UTF-8); 0/90/180/270° rotation |
| Barcodes |
1D: Code 39, Code 93, Code 128 (UCC, subsets A/B/C), Codabar, Interleaved 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN/UPC add-on, MSI, Plessey, Postnet, China Post, ITF-14, EAN-14, Code 11, Telepen, Planet, Code 49, Deutsche Post Identcode/Leitcode, LOGMARS; 2D: TLC39, Codablock F, PDF417, MicroPDF417, MaxiCode, DataMatrix, QR Code, Aztec, GS1 DataBar |
| Display |
3.5" colour touch display (480 × 320 px); power, feed, pause and reprint buttons |
| Media Options |
Linerless cutter kit: non-stick linerless platen roller and cutter, full cut (factory-fitted) |
| Options |
Peel-off module, guillotine cutter, linerless tear-off kit, linerless cutter kit, Wi-Fi + Bluetooth 5.0 combo module, Bluetooth 5.0 module, MFi Bluetooth 5.0 (factory option), external label roll mount, KP-200 Plus keyboard, 10 mm narrow media adaptor, BP-4000 battery pack |
| Management & Security |
Internal embedded web page, virtual control panel, TSC Console, SOTI Connect (licence); HTTPS, SNMPv3, 802.1X, TCP/IP port 9100 filter; TPH Care printhead diagnostics |
| Power Supply |
External universal switching power supply: 100–240 V AC, 2.0 A, 50–60 Hz input; 24 V DC, 3.75 A, 90 W output |
| Dimensions (W × D × H) |
208 × 235 × 170 mm (W × D × H) |
| Weight |
2.1 kg |
| Color |
Black |
| Operating Temperature |
0–40 °C, 25–85% RH non-condensing |
| Storage Temperature |
−40–60 °C, 10–90% RH non-condensing |
| Certifications |
CB, FCC Class B, IC, cTÜVus, NOM, CE Class B, UKCA, EAC, CCC, BIS, RCM, KC, ENERGY STAR 3.0; RoHS, REACH, WEEE |
| Warranty |
Printer: 3 years (TSC EMEA, purchases from 1 June 2024); printhead 25 km or 12 months, platen 50 km or 12 months (whichever comes first) |
| In the Box |
TSC DH240T printer (203 dpi, 3.5" colour touch LCD, USB 2.0 + RS-232 + Ethernet + USB host, factory-fitted linerless cutter kit (linerless platen roller + cutter)), external power supply (24 V DC, 90 W), power cord (EU Schuko plug), USB cable, quick start guide – linerless labels NOT included (direct thermal, no ribbon needed) |
