The TSC TC210 (99-059A009-1002) is a space-saving 4-inch desktop label printer for thermal-transfer and direct-thermal printing at 203 dpi and up to 152 mm/s (6 ips). It takes 127 mm label rolls up to 112 mm wide and 110 m ribbons, runs TSPL-EZ with EPL and ZPL emulation, has a 2.3" colour display with six control buttons, and connects via USB 2.0, USB host, RS-232 and 10/100 Ethernet. Supplied with power supply, EU power cord and USB cable – ready to print. This version has a beige housing.
📦 What's in the box – 99-059A009-1002
- TSC TC210 label printer – 203 dpi, 2.3" colour display, USB 2.0, USB host, RS-232, Ethernet 10/100
- Power supply – external universal power supply, 100–240 V AC → 24 V DC, 90 W
- Power cord – EU plug (Schuko)
- USB cable – USB 2.0 A-to-B – connect and print straight away
- Windows drivers & labeling software – TSC driver and labeling software (CD or free download from TSC)
- Setup guide
Ready to print: power supply, power cord and USB cable are in the box – you only need labels (and a ribbon for thermal-transfer printing).
💡 To get started, you might also consider compatible labels for your application and, for thermal-transfer printing, a ribbon – plus a standard Ethernet cable for network use.
Key Features
- Thermal transfer and direct thermal at 203 dpi – up to 152 mm/s (6 ips), max. print width 108 mm
- Easy ribbon loading: 110 m ribbons on a 0.5" core (ink outside), 40–110 mm wide
- 127 mm (5") label rolls on 25.4–38.1 mm cores, media 20–112 mm wide; centre-biased, spring-loaded media guides and fanfold feed
- 32-bit RISC processor with 64 MB SDRAM, 128 MB Flash and an SD card slot (up to 32 GB)
- TSPL-EZ firmware with EPL and ZPL/ZPL II emulation, file manager, BASIC programming and stand-alone operation
- USB 2.0, RS-232 and 10/100 Ethernet as standard, plus a USB host port for a scanner or keyboard
- 2.3" colour TFT display (320 × 240 px) with six buttons for menu-driven setup without a PC
- Transmissive gap, adjustable black-mark, ribbon-end and head-open sensors
- Dealer options: guillotine cutter and peel-off module; double-walled clamshell, ENERGY STAR qualified
Ideal Applications
- Retail point of sale – price tags, product marking and coupons
- Compliance and product labels in light manufacturing
- Asset tracking and inventory control
- Shipping and receiving labels
- Healthcare – specimen labels and patient tracking
- Document management and file labels
All TC Series Versions
The highlighted row is the version you are currently viewing.
| Part Number | Model | Resolution | Interfaces | Display | Wireless | Color | |
|---|---|---|---|---|---|---|---|
| 99-059A003-6002 | TC200 | 203 dpi | USB, RS-232, parallel, Ethernet | LED (no display) | — | Navy | View product |
| 99-059A004-7002 | TC300 | 300 dpi | USB, RS-232, parallel, Ethernet | LED (no display) | — | Navy | View product |
| 99-059A001-1002 | TC210 | 203 dpi | USB, USB host, RS-232, Ethernet | 2.3" colour display | — | Navy | View product |
| 99-059A001-1202 | TC210 | 203 dpi | USB, USB host, RS-232, Ethernet | 2.3" colour display | Wi-Fi + Bluetooth | Navy | View product |
| 99-059A009-1002 (this version) | TC210 | 203 dpi | USB, USB host, RS-232, Ethernet | 2.3" colour display | — | Beige | Viewing |
| 99-059A002-3002 | TC310 | 300 dpi | USB, USB host, RS-232, Ethernet | 2.3" colour display | — | Navy | View product |
| 99-059A002-3202 | TC310 | 300 dpi | USB, USB host, RS-232, Ethernet | 2.3" colour display | Wi-Fi + Bluetooth | Navy | View product |
Technical Specifications
| Part Number | 99-059A009-1002 |
|---|---|
| Model | TSC TC210 (TC Series) |
| Printer Type | 4-inch desktop thermal transfer label printer |
| Print Method | Thermal transfer and direct thermal |
| Resolution | 203 dpi (8 dots/mm) |
| Print Speed | Up to 152 mm/s (6 ips) |
| Max Print Width | 108 mm (4.25") |
| Max Print Length | 25,400 mm (1,000") |
| Media Width | 20–112 mm (0.79"–4.4") |
| Media Thickness | 0.06–0.19 mm (2.36–7.48 mil) |
| Roll Diameter | 127 mm (5") OD inside the printer; larger rolls with the optional external roll mount |
| Core Size | 25.4–38.1 mm (1"–1.5") |
| Media Types | Continuous, die-cut, black mark, fanfold, notched; label length 10 mm – 25,400 mm |
| Sensors | Transmissive gap sensor, reflective black-mark sensor (position adjustable), ribbon-end sensor, head-open sensor |
| Ribbon | 110 m on 0.5" (12.7 mm) core, max. OD 40 mm; width 40–110 mm; ink coated OUTSIDE |
| Interfaces | USB 2.0 (high speed), USB host, RS-232 serial, internal Ethernet 10/100 Mbps; SD card slot |
| Wireless | None as standard – optional external Bluetooth or 802.11 b/g/n Wi-Fi module (serial interface) |
| Processor | 32-bit RISC CPU |
| Memory | 64 MB SDRAM, 128 MB Flash; SD card up to 32 GB |
| Real-Time Clock | Yes |
| Printer Languages | TSPL-EZ (EPL, ZPL, ZPL II compatible); file manager, BASIC programming, stand-alone operation |
| Fonts / Character Sets | 8 alphanumeric bitmap fonts; Monotype true-type engine with CG Triumvirate Bold Condensed scalable font; 0/90/180/270° rotation |
| Barcodes | 1D: Code 39, Code 93, Code 128 (UCC, subsets A/B/C), Codabar, Interleaved 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, MSI, Plessey, Postnet, LOGMARS, Code 11, Code 49, China Post, ITF-14, Telepen, Planet, Deutsche Post Identcode/Leitcode; 2D: GS1 DataBar, GS1 DataMatrix, MaxiCode, Aztec, PDF417, MicroPDF417, QR Code |
| Display | 2.3" colour TFT display (320 × 240 px), 6 operation buttons (menu, feed/pause, up, down, left, right), three-colour LED |
| Media Options | Tear-off (standard); dealer options: guillotine cutter (full cut), peel-off module |
| Options | External roll mount; KP-200 Plus keyboard display unit; KU-007 Plus programmable smart keyboard; external Bluetooth / Wi-Fi module (serial) |
| Drivers & Software | Windows drivers and TSC labeling software (CD / free download), TSC Console |
| Power Supply | External universal switching power supply: 100–240 V AC, 2.5 A, 50–60 Hz input; 24 V DC, 3.75 A, 90 W output |
| Dimensions (W × D × H) | 203 × 259.3 × 191.5 mm (W × D × H) |
| Weight | 2.3 kg |
| Color | Beige |
| Enclosure | Double-walled plastic clamshell |
| Operating Temperature | 5–40 °C, 25–85% RH non-condensing |
| Storage Temperature | −40–60 °C, 10–90% RH non-condensing |
| Certifications | FCC Class B, CE Class B, C-Tick Class B, UL, cUL, TÜV/Safety, CCC, ENERGY STAR; RoHS, WEEE |
| Warranty | Printer: 3 years (TSC EMEA, purchases from 1 June 2024); printhead 25 km or 12 months, platen 50 km or 12 months (whichever comes first) |
| In the Box | TSC TC210 printer (203 dpi, 2.3" colour display, USB 2.0, USB host, RS-232, Ethernet 10/100, beige), external universal power supply (24 V DC, 90 W), power cord (EU Schuko plug), USB cable, Windows labeling software (CD or download), quick start guide |
Need a different interface, resolution or wireless option? All TC Series versions are listed above. Compare other models in our Desktop Label Printers collection or contact our team for volume pricing.
