Zebra MP7200 Countertop Barcode Scanner (MP7200-MNS0N000WW)

The Zebra MP7200 (MP72 Series) is Zebra's latest multi-plane (bioptic) in-counter scanner, built for the fastest possible checkout in high-volume lanes and at self-checkouts. Mounted flush in the checkout counter, it reads virtually every 1D, 2D, GS1 Digital Link and Digimarc barcode – on labels, packaging and phone screens – through its horizontal and vertical scan windows, so cashiers and customers rarely need to turn an item. This version, MP7200-MNS0N000WW, has a medium (398 mm) platter and sapphire scan glass. It is supplied as the scanner only – the host cable and power supply are ordered separately.

Key Features

• Premium scanning on every plane – a high-resolution megapixel sensor and Zebra's PRZM Intelligent Imaging read virtually any 1D, 2D, GS1 DataBar, GS1 Digital Link and Digimarc barcode on paper labels, packaging and phone screens – even poorly printed, damaged, crinkled or faded codes.
• Up to 2× larger fields of view – high swipe speeds and fields of view up to 100% larger than other scanners in its class mean there is less need to position barcodes carefully; offset illumination makes reflective phone screens and glossy packaging easy to scan.
• Non-Decode Event alerts – trigger an alert in your POS or loss-prevention software whenever an item passes through the field of view without a barcode being scanned, whether accidental or intentional.
• EAS support – compatible with Checkpoint and Sensormatic EAS deactivation systems: one swipe captures the price and deactivates the tag; Checkpoint Interlock (optional cable) only deactivates a tag when the barcode has been scanned.
• Good-decode LED on the front and top – cashiers, self-checkout attendants and overhead loss-prevention cameras can confirm every successful scan.
• Eye-friendly and energy-efficient – the recessed intelligent illumination is dimmed when no item is in the scan zone, so the MP72 uses up to 50% less power than other bioptic scanners (2.0 W idle, 2.75 W active, typical).
• Three standard sizes – short (351 mm), medium (398 mm) and long (506 mm) platters drop right into existing cash-wrap cut-outs; choose sapphire or DLC-coated glass, and a spill-proof design protects against inevitable spills.
• Built for maximum uptime – over 50% fewer interconnects and PCBs than other multi-plane scanners, solid-state technology and Zebra Remote Diagnostics for illumination, sensors, cameras and boards keep repairs to a minimum.
• Connects to any POS – one shared POS port for USB, RS232 or IBM 46xx (RS485) with auto-host-detect cables, plus three USB and two powered RS232 peripheral ports for a handheld scanner, a Checkpoint Interlock port and a remote scale display port.
• Zebra DataCapture DNA – 123Scan, Scanner SDK, Scanner Management Service (SMS), Advanced Data Formatting and IoT Connector; selectable label identifiers can, for example, convert a QR code into Code 128 to avoid exceptions.

Ideal Applications

• Supermarkets, hypermarkets and grocery stores – high-volume cashier lanes
• Mass merchandisers, discount chains and warehouse clubs
• Self-checkout systems in any retailer – with Non-Decode Event alerts, top-visible good-decode LED and optional color camera for loss prevention
• Pharmacies and drugstores – paper and mobile barcodes, GS1 DataBar and GS1 Digital Link
• Retailers modernising existing checkouts – the three standard sizes fit existing counter cut-outs

All MP7200 Versions

The highlighted row is the version you are currently viewing.

Technical Specifications

Not sure which version you need? First choose the platter length that fits your checkout counter: short MP7200-SNS0N000WW, medium (for example MP7200-MNS0N000WW) or long MP7200-LNS0N000WW. Sapphire glass is the most scratch-resistant choice for busy grocery lanes, while DLC-coated glass (MP7200-MNDLN000WW, MP7200-MNDLL000WW) is the more economical option; versions with the HD color camera (MP7200-MNSLL000WW, MP7200-MNDLL000WW) add computer-vision and loss-prevention capabilities. Remember to add a host cable and, if needed, a power supply. Compare other checkout scanners in our Presentation Barcode Scanners and In-Counter Barcode Scanners collections or contact our team for volume pricing.
