TSC DA210 Desktop Label Printer (99-158A005-0202)

Regular price 327,60 € +VAT
In the Box
Power Cord
EUUK
Resolution (dpi)
203300
Wireless
BluetoothNoneWi-Fi
Wired Interfaces
Linerless
NoYes
Color
BlackWhite

Free Shipping over 250 €. Usually delivered within 3–5 working days.

0% VAT for EU/EEA companies (excl. Estonia). Enter a valid VAT number to automatically generate a 0% VAT invoice.

TSC DA210 4-inch direct thermal desktop label printer, 203 dpi, USB + MFi Bluetooth, black (99-158A005-0202) – front view
TSC
TSC DA210 Desktop Label Printer (99-158A005-0202)
Regular price 327,60 € +VAT

The TSC DA210 (99-158A005-0202) is a compact 4-inch direct-thermal desktop label printer that prints at 203 dpi and up to 152 mm/s (6 ips) – no ribbon needed. Its double-walled clamshell takes 127 mm label rolls up to 114 mm wide, the TSPL-EZD firmware emulates EPL, ZPL and DPL, and it connects via USB 2.0 plus built-in MFi Bluetooth for iOS and Android. Supplied with power supply, EU power cord and USB cable – ready to print.

📦 What's in the box – 99-158A005-0202

  • ✅ TSC DA210 label printer – 203 dpi, USB 2.0 + MFi Bluetooth
  • ✅ Power supply – external universal power supply, 100–240 V AC → 24 V DC, 60 W
  • ✅ Power cord – EU plug (Schuko)
  • ✅ USB cable – USB 2.0 A-to-B – connect and print straight away
  • ✅ Windows drivers & labeling software – TSC driver and labeling software (CD or free download from TSC)
  • ✅ Setup guide
  • ❌ Labels – NOT included – order labels to suit your application (see compatible labels below)

✅ Ready to print: power supply, power cord and USB cable are in the box – you only need direct-thermal labels (no ribbon required).

💡 Useful extras: direct-thermal labels such as the TSC 38-T100150-12LF (100 × 150 mm shipping labels); the TSC OP-COM-0002 external roll mount for large 214 mm (8.4") rolls on 3" cores.

Key Features

  • Direct thermal at 203 dpi – up to 152 mm/s (6 ips), max. print width 108 mm; no ribbon to buy or change
  • Compact double-walled clamshell (172 × 195 × 165 mm, 1.5 kg) with easy drop-in media loading
  • 127 mm (5") label rolls on 25.4–38 mm cores, media 19–114 mm wide; continuous, gap, black-mark, fanfold and notched media
  • 32-bit RISC processor with 16 MB DRAM and 8 MB Flash memory
  • TSPL-EZD firmware with EPL, ZPL/ZPL II and DPL emulation – a drop-in replacement for existing label printers
  • USB 2.0 plus built-in MFi Bluetooth for printing from iPhone, iPad and Android devices
  • Transmissive gap sensor, black-mark sensor and head-open sensor
  • Simple one-button operation with a three-colour status LED; ENERGY STAR qualified
  • Easy printhead and platen roller replacement; 3-year TSC warranty in EMEA

Ideal Applications

  • Small parcel shipping and e-commerce dispatch labels
  • Mail room address and routing labels
  • Shipping and receiving in warehouses and logistics
  • Retail point of sale – price, shelf and product labels
  • Entertainment and transportation ticketing
  • File-folder and office labelling

All DA Series Versions

The highlighted row is the version you are currently viewing.

Part Number Model Resolution Interfaces Wireless Power Cord Color Media Option
99-158A001-0002 DA210 203 dpi USB — EU (Schuko) Black Tear-off View product
99-158A001-0003 DA210 203 dpi USB — UK Black Tear-off View product
99-158A005-0202 (this version) DA210 203 dpi USB Bluetooth (MFi) EU (Schuko) Black Tear-off Viewing
99-158A002-0002 DA310 300 dpi USB — EU (Schuko) Black Tear-off View product
99-158A013-1102 DA220 203 dpi USB, USB host, RS-232, Ethernet — EU (Schuko) Black Tear-off View product
99-158A028-1502 DA220 203 dpi USB, USB host, RS-232, Ethernet Bluetooth 4.0 EU (Schuko) Black Tear-off View product
99-158A015-2102 DA220 203 dpi USB, Ethernet — EU (Schuko) Black Tear-off View product
99-158A025-2702 DA220 203 dpi USB, Ethernet Wi-Fi EU (Schuko) Black Tear-off View product
99-158A015-2152 DA220 203 dpi USB, Ethernet — EU (Schuko) Black Linerless cutter View product
99-158A016-2102 DA320 300 dpi USB, USB host, RS-232, Ethernet — EU (Schuko) Black Tear-off View product
99-158A020-1702 DA320 300 dpi USB, USB host, RS-232, Ethernet Wi-Fi EU (Schuko) Black Tear-off View product
99-158A020-20LF DA320 300 dpi USB, USB host, RS-232, Ethernet Wi-Fi UK Black Tear-off View product
DA220W-A001-1102 DA220W 203 dpi USB, USB host, RS-232, Ethernet — EU (Schuko) White Tear-off View product
DA220W-A001-2102 DA220W 203 dpi USB, Ethernet — EU (Schuko) White Tear-off View product
DA220W-A001-21C2 DA220W 203 dpi USB, Ethernet — EU (Schuko) White External roll mount View product

Technical Specifications

Part Number 99-158A005-0202
Model TSC DA210 (DA Series)
Printer Type 4-inch desktop direct thermal label printer
Print Method Direct thermal (no ribbon)
Resolution 203 dpi (8 dots/mm)
Print Speed Up to 152 mm/s (6 ips)
Max Print Width 108 mm (4.25")
Max Print Length 2,794 mm (110")
Media Width 19–114 mm (0.7"–4.5")
Media Thickness 0.055–0.19 mm (2.16–7.48 mil)
Roll Diameter 127 mm (5") OD inside the printer; up to 214 mm (8.4") OD on 3" core with the optional external roll mount
Core Size 25.4–38 mm (1"–1.5")
Media Types Continuous, die-cut (gap), black mark, fanfold, notched (outside wound); direct-thermal media; label length 10 mm – 2,794 mm
Sensors Transmissive gap sensor, black-mark reflective sensor, head-open sensor
Interfaces USB 2.0 (high speed)
Wireless Internal MFi Bluetooth (factory-installed, iOS and Android)
Processor 32-bit RISC CPU
Memory 16 MB DRAM, 8 MB Flash
Real-Time Clock No
Printer Languages TSPL-EZD (EPL, ZPL, ZPL II and DPL compatible)
Fonts / Character Sets 8 alphanumeric bitmap fonts; Monotype true-type engine with CG Triumvirate Bold Condensed scalable font; 0/90/180/270° rotation
Barcodes 1D: Code 39, Code 93, Code 128 (UCC, subsets A/B/C), Codabar, Interleaved 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN/UPC 2(5)-digit add-on, MSI, Plessey, Postnet, RSS-Stacked, GS1 DataBar, Code 11, China Post; 2D: PDF417, MicroPDF417, MaxiCode, DataMatrix, QR Code, Aztec
Display No LCD – 1 three-colour status LED (green/amber/red), 1 feed button, power switch
Media Options Tear-off (no cutter or peeler option)
Options 1.5" core adaptor; external roll mount (214 mm OD, 3" core)
Drivers & Software Windows drivers and TSC labeling software (CD / free download), TSC Console
Power Supply External universal switching power supply: 100–240 V AC, 50–60 Hz input; 24 V DC, 2.5 A, 60 W output
Dimensions (W × D × H) 172 × 195 × 165 mm (W × D × H)
Weight 1.5 kg
Color Black
Enclosure Double-walled plastic clamshell
Operating Temperature 5–40 °C, 25–85% RH non-condensing
Storage Temperature −40–60 °C, 10–90% RH non-condensing
Certifications FCC Class A, CE Class A, RCM, CB, CCC, ENERGY STAR, KC, BIS, UL, EAC; RoHS, WEEE
Warranty Printer: 3 years (TSC EMEA, purchases from 1 June 2024); printhead 25 km or 12 months, platen 50 km or 12 months (whichever comes first)
In the Box TSC DA210 printer (203 dpi, USB 2.0 + MFi Bluetooth), external universal power supply (24 V DC, 60 W), power cord (EU Schuko plug), USB cable, Windows labeling software (CD or download), quick start guide – labels NOT included

Need a different interface, resolution, plug or the healthcare version? All DA Series versions are listed above. Compare other models in our Desktop Label Printers collection or contact our team for volume pricing.
