CipherLab WR30 Series Wearable Ring Scanner (AR30SRHE00001)

The CipherLab WR30 is a compact wearable ring scanner that keeps both hands free for picking, sorting and packing. Weighing only 59 g with battery, it reads 1D and 2D barcodes, connects to smartphones, tablets, mobile computers and PCs via Bluetooth 5.3 Low Energy and pairs in seconds with an NFC tap or a pairing barcode. The quick-release 600 mAh battery lasts up to 8 hours, and IP65 sealing with 1.8 m drop resistance makes the WR30 ready for demanding warehouse work. This version, AR30SRHE00001, has the standard range SE4770 2D imager and comes with the ambidextrous hand mount strap with trigger, battery and a USB-C charging set with EU power supply.

Key Features

• Hand mount strap kit – the ambidextrous strap holds the scanner securely on the back of the hand with the trigger at your fingertips – comfortable for long picking shifts.
• SE4770 standard range 2D imager – a 1280 × 800 pixel sensor with a wide field of view reads 1D and 2D barcodes quickly from close contact to arm's length, including small, damaged or poorly printed labels.
• Quick-release 600 mAh battery – up to 8 hours of operation (one scan every 5 seconds); the battery is swapped in seconds, so a charged spare keeps the scanner running from shift to shift.
• Compact and light – only 59 g with battery and 62.8 × 31.8 × 17.3 mm, comfortable for all-day wear on either hand.
• Bluetooth 5.3 Low Energy with NFC – energy-saving wireless connection with quick pairing by NFC tap or pairing barcode; works directly with Android devices, tablets, mobile computers and PCs.
• Three interchangeable wearing options – ring trigger, ambidextrous hand mount strap with trigger, or detachable trigger with lanyard; hand mount gloves with side trigger for the left or right hand are also available.
• Rugged for the warehouse – IP65 sealing against dust and water jets, 1.8 m drops and 1,000 tumbles, operation from −20 °C to 50 °C.
• Instant feedback – buzzer, LED and vibration confirm every scan, even in noisy environments.

Ideal Applications

• Warehouse order picking, put-away and replenishment – with both hands free
• Goods receiving, parcel sorting and cross-docking in distribution centres
• Scanning pallet and high-rack labels from a forklift (SE5500 versions)
• Manufacturing – kitting, line-side supply and parts tracking
• Retail back-of-store, shelf replenishment and stocktaking
• Courier, logistics and e-commerce order fulfilment

All WR30 Versions

The highlighted row is the version you are currently viewing.

Technical Specifications

Compare the WR30 with other wireless models in our Cordless / Wireless Barcode Scanners collection, or contact our team for advice on a complete wearable setup with spare batteries, wearing accessories and volume pricing.
