MB241 Series: Loading the ribbon & media

TSC MB341 Label Printer (MB341-A001-0202)

Name: TSC MB341 Label Printer (MB341-A001-0202)
Brand: TSC
SKU: tscmb341
Availability: OutOfStock

950,04 € +VAT

Product variants

Resolution (dpi)

203300

Display

2.3-inch colour LCD3.5-inch colour touch LCD

Notify me when in stock

Free Shipping over 250 €. Usually delivered within 3–5 working days.

0% VAT for EU/EEA companies (excl. Estonia). Enter a valid VAT number to automatically generate a 0% VAT invoice.

Available: Out Of Stock
Vendor: TSC
Type: Industrial Printers
Barcode: MB341-A001-0202
Collections: Industrial Label Printers , Label Printers

📄 Download Product Brochure (PDF)

TSC

TSC MB341 Label Printer (MB341-A001-0202)

950,04 € +VAT

Description

Description

The TSC MB341 from the MB241 Series is a rugged, space-saving industrial label printer: its bi-fold media door cuts the space needed for operation by 24%, while the all-metal print mechanism on a metal frame handles high volumes as well as thicker tags and hangtags. It prints in thermal transfer and direct thermal at 300 dpi and up to 229 mm/s, takes 203 mm (8-inch) label rolls on 1- to 3-inch cores and 450 m ribbons, and connects via USB, RS-232, Ethernet and USB host as standard. This version, MB341-A001-0202, has a 2.3-inch colour LCD with six-button menu navigation.

📦 What's in the box – MB341-A001-0202

✅ TSC MB341 label printer – 300 dpi, built-in power supply 100–240 V
✅ Power cords – EU (Schuko) and UK (type G) plugs – use the one for your country
✅ USB cable – USB A to B, for connecting to your PC
✅ Setup guide – quick start guide; drivers, TSC Console and labeling software are a free download from TSC
❌ Labels – NOT included
❌ Thermal transfer ribbon – NOT included
❌ Ethernet (LAN) cable – NOT included

✅ Ready to print out of the box – the power supply is built in, and the power cord and USB cable are included; you only need labels and a thermal transfer ribbon (direct thermal labels print without a ribbon). For a network connection, use the built-in Ethernet port with a standard RJ45 patch cable (not included).

💡 Useful extras: matching labels (TSC 38-T102102-10LF or TSC 38-S078130-1031); ribbons up to 450 m (TSC P159049-001 or TSC P159079-001); upgrade options: peel-off kit (TSC PEL-MB240-0001), cutter (TSC CUT-MB240-0001), internal rewinder kit (TSC REW-MB240-0001), linerless cutter kit (TSC CUT-MB240-0002), Wi-Fi + Bluetooth module (TSC WF-COM-2002).

Key Features

Space-saving bi-fold door – reduces the space needed for media and ribbon changes and cleaning by 24%; a robust all-metal print mechanism on a metal frame ensures stable printing and a long printer life.
2.3-inch colour LCD – clear status and menu display with six-button navigation (Menu, Pause/Feed and arrow keys).
Thermal transfer and direct thermal – up to 229 mm/s at 300 dpi with a maximum print width of 105.7 mm.
Large media capacity – label rolls up to 203 mm in diameter on 25–76 mm cores, media 20–120 mm wide; continuous, die-cut, black-mark, notched and fanfold media.
450 m ribbons – long ribbons on a 1-inch core mean fewer changes; ribbons coated inside or outside both work.
Flexible connectivity – USB 2.0, RS-232, 10/100 Ethernet and USB host as standard; optional slot-in Wi-Fi 802.11ac + Bluetooth 5.0 module, internal Bluetooth or GPIO.
TSC Sense Care and remote management – self-diagnostic printhead care, near real-time status and warnings, plus SOTI Connect and TSC Console for remote fleet management.
Auto-switching emulation – TSPL-EZD with EPL, ZPL, ZPL II and DPL simplifies fleet migration; TSC Standalone Creator and TSCPRTGo add LCD templates and mobile printing.
Sustainable design – 100% recyclable packaging and printer casing, with over 90% recyclable printer components.
Fits diverse applications – peel-off kit, guillotine cutter, internal rewinder kit (5-inch OD), linerless cutter and tear-off kits, Wi-Fi + Bluetooth module and KP-200 Plus keyboard display.

Ideal Applications

Manufacturing – work-in-process, product marking, compliance and industrial-duty labels
Transport and logistics – packing, order fulfilment, shipping and receiving, pallet labels
Warehousing – inventory, location and asset labels
Healthcare and pharma – specimen, pharmaceutical and asset tracking labels
Retail and food – product, price, weighing scale and food packaging labels

All MB241 Versions

The highlighted row is the version you are currently viewing.

Part Number	Model	Resolution	Display
MB241-A001-0202	TSC MB241	203 dpi	2.3" colour LCD	View product
MB241T-A001-0202	TSC MB241T	203 dpi	3.5" colour touch	View product
MB341-A001-0202 (this version)	TSC MB341	300 dpi	2.3" colour LCD	Viewing
MB341T-A001-0202	TSC MB341T	300 dpi	3.5" colour touch	View product

Technical Specifications

Part Number	MB341-A001-0202
Model	TSC MB341 (MB241 Series)
Printer Type	4-inch industrial label printer – MB241 Series
Construction	Die-cast print mechanism on metal frame; metal cover with large clear media window; bi-fold media door (24% less operating space)
Print Method	Thermal transfer and direct thermal
Resolution	300 dpi (12 dots/mm)
Print Speed	Up to 229 mm/s (9 ips)
Max Print Width	105.7 mm (4.16")
Max Print Length	11,430 mm (450")
Min. Label Length	5 mm
Media Width	20–120 mm (0.8"–4.7")
Media Thickness	0.06–0.28 mm (2.36–11 mil)
Roll Diameter	203.2 mm (8") OD
Core Size	25.4–76.2 mm (1"–3")
Media Types	Continuous, die-cut, black mark, fanfold, notched (outside wound); linerless with optional linerless kits
Sensors	Gap transmissive (position adjustable), black mark reflective (position adjustable), ribbon encoder, ribbon end, head open
Ribbon	Max. 450 m, 1" (25.4 mm) core, ink coated outside or inside; width 40–110 mm
Media Options	Tear-off (standard); options: peel-off kit (factory), guillotine cutter, 5" OD internal rewinder kit, linerless cutter kit, linerless tear-off kit (dealer)
Interfaces	USB 2.0, RS-232, internal Ethernet 10/100 Mbps, USB host (for scanner or PC keyboard); GPIO (dealer option)
Wireless	None as standard; options: internal Bluetooth 5.0 MFi (factory), internal Bluetooth or slot-in Wi-Fi 802.11a/b/g/n/ac + Bluetooth 5.0 combo module (dealer); GPIO or wireless – one at a time
Processor	32-bit RISC CPU
Memory	256 MB Flash, 256 MB SDRAM
Real-Time Clock	Standard
Printer Languages	TSPL-EZD (EPL, ZPL, ZPL II, DPL) with auto-switching emulation
Fonts / Character Sets	8 alphanumeric bitmap fonts; Monotype Imaging true type font engine with CG Triumvirate Bold Condensed scalable font; 0/90/180/270° rotation
Barcodes	1D: Code 39, Code 93, Code 128 (UCC, subsets A/B/C), Codabar, Interleaved 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN/UPC 2/5-digit add-on, MSI, Plessey, POSTNET, RSS-Stacked, GS1 DataBar, Code 11, China Post; 2D: PDF417, Micro PDF417, MaxiCode, DataMatrix, QR Code, Aztec, TLC 39, RSS
Display	2.3" colour LCD; 6 buttons (Menu, Pause/Feed, Up, Down, Left, Right); 1 LED (green/red); power switch
Options	Peel-off kit, guillotine cutter, internal rewinder kit, linerless cutter / tear-off kits, GPIO, internal Bluetooth, Wi-Fi + Bluetooth module, KP-200 Plus keyboard display, universal cutter tray
Drivers & Software	Windows drivers, TSC Console, SOTI Connect, Internal Embedded Webpage, TSC Standalone Creator, TSCPRTGo; TSC Sense Care
Power Supply	Internal universal switching power supply: 100–240 V AC, 2.0 A, 50–60 Hz; output 24 V DC, 3.75 A, 90 W
Dimensions (W × D × H)	248 × 436 × 274 mm
Weight	9.1 kg
Operating Temperature	0–40 °C, 25–85% RH non-condensing
Storage Temperature	−40–60 °C, 10–90% RH non-condensing
Certifications	CB, FCC Class A, CE Class A, UKCA, RCM Class A, cTUVus, TÜV, IC Class A, NOM, VCCI, CCC, BIS, KC, BSMI, EAC, ENERGY STAR; RoHS, WEEE
Warranty	Printer: 2 years; printhead 25 km or 12 months, platen 50 km or 12 months (whichever comes first)
In the Box	TSC MB341 printer (300 dpi, built-in power supply), power cords EU + UK, USB cable, quick start guide – labels, ribbon and Ethernet cable NOT included

Which MB241 should you choose? 203 dpi is the fastest choice for barcodes and shipping labels; 300 dpi gives crisper small text, logos and fine 2D codes. The standard models have a 2.3-inch colour LCD, the T models a 3.5-inch colour touchscreen. Compare other models in our Industrial Label Printers collection or contact our team for volume pricing.
