The Newland WD4 (Nwear by Newland) is a lightweight Bluetooth® ring scanner worn on the finger, so both hands stay free for picking, carrying and packing. Its 2D imager reads 1D and 2D barcodes, the rotating scan head fits the left or right hand, and a light press of the thumb triggers each scan. The WD4 connects via Bluetooth 5.0 to Android, iOS and Windows smartphones, tablets, mobile computers and PCs, and its 670 mAh battery lasts a full shift. This version, WD4-BS20-SR, is supplied with a magnetic USB charging cable – ready to pair and scan.
📦 What's in the box – WD4-BS20-SR
- ✅ Newland WD4 ring scanner – black, 2D imager, Bluetooth 5.0 – worn on the finger with an adjustable strap; rotating head for left- or right-hand use
- ✅ Rechargeable battery – Li-ion, 4.35 V, 670 mAh, built in – up to 8 hours of scanning, fully charged in under 2 hours
- ✅ Magnetic USB cable – USB-A to magnetic connector – charges the scanner from a USB port on your PC or a USB adapter; also works as a wired USB connection and for EasySet configuration
- ❌ Charging cradle – not included – optional; not needed, as the scanner charges with the included cable
- ❌ Power supply – not included – not needed – the scanner charges from any USB port (5 V, 1 A); a USB power adapter is available as an option
- ❌ Bluetooth USB dongle – not included – not needed for smartphones, tablets and PCs with built-in Bluetooth; optional for PCs without Bluetooth
💡 How it connects: the WD4 pairs directly with your smartphone, tablet, mobile computer or PC via Bluetooth 5.0 and types scanned data like a keyboard (HID) – no base station, driver or app needed. The free Newland EasyConnect app (Android, iOS, Windows) makes pairing even easier: simply scan the pairing barcode shown in the app. For a Windows PC without Bluetooth, add the Bluetooth USB dongle (Newland NLS-DG-R). Out of range? In batch mode, more than 16,000 EAN-13 codes are stored in the 1 MB memory for later upload.
🔌 Charging: attach the magnetic cable to the scanner and plug it into a PC USB port or a USB power adapter (Newland ADP710). For several scanners: Newland NLS-SCD20 2-slot charging cradle – charges two WD4 at once (USB-C cable included); up to five cradles can be linked to charge ten scanners from one power supply (Newland AD60-D-M).
Key Features
- Hands-free scanning – the ring is worn on the finger with an adjustable strap, the rotating head fits the left and right hand, and the trigger is pressed lightly with the thumb – ideal while carrying boxes or picking orders.
- 1D and 2D codes – a 640 × 480 image sensor with white LED illumination and a red LED aimer reads QR Code, Data Matrix, PDF417, Aztec and all common 1D barcodes; EAN-13 (13 mil) from 55 to 280 mm.
- Bluetooth 5.0 – pairs with Android, iOS and Windows smartphones, tablets, mobile computers and PCs, with up to 40 m range in open space; the EasyConnect app makes pairing simple.
- Batch mode with 1 MB memory – stores more than 16,000 EAN-13 codes when out of range and uploads them later.
- Full-shift battery – the 670 mAh Li-ion battery and low-power Bluetooth 5.0 deliver up to 8 hours of scanning (depending on scanning intensity); fully charged in under 2 hours.
- Easy charging – a magnetic USB cable is included; optional 2-slot charging cradles can be daisy-chained (up to five) to charge ten scanners from a single power supply.
- Clear feedback – LED, beep and vibration confirm every good read and signal Bluetooth connection and battery status.
- Light and robust – just 48 g, IP42 sealing, 1.2 m drop rating, operating temperature −20 °C to 50 °C, configuration with EasySet software and a 3-year Newland warranty.
Ideal Applications
- Warehouse order picking, put-away and replenishment – with both hands free
- Logistics – goods receiving, parcel sorting and truck loading
- E-commerce order fulfilment and packing
- Retail – shelf replenishment, stocktaking and click & collect
- Events and entertainment – ticket checks at entrances
- Manufacturing – kitting and parts tracking
Technical Specifications
| Part Number | WD4-BS20-SR |
|---|---|
| Model | Newland WD4 Ring Scanner (Nwear by Newland) |
| Scanner Type | Bluetooth wearable ring scanner – 2D area imager (reads 1D and 2D barcodes) |
| Image Sensor | 640 × 480 CMOS |
| Aimer | Red LED |
| Illumination | White LED |
| Maximum Resolution | ≥ 3 mil (Code 128) |
| Depth of Field (typical) | EAN-13 13 mil: 55–280 mm; Code 39 5 mil: 55–145 mm; PDF417 6.7 mil: 40–130 mm; Data Matrix 10 mil: 40–140 mm; QR Code 15 mil: 30–195 mm |
| Reading Angles | Pitch ±60°, roll 360°, skew ±60° |
| Minimum Print Contrast | 20% (Code 128, 10 mil) |
| 1D Symbologies | Code 128, GS1-128 (UCC/EAN-128), AIM 128, EAN-8, EAN-13, ISBN/ISSN, UPC-A, UPC-E, Standard 2 of 5, Industrial 2 of 5, Interleaved 2 of 5, Matrix 2 of 5, ITF-6, ITF-14, Codabar, Code 39, Code 93, Code 11, Plessey, MSI Plessey, GS1 DataBar (RSS) |
| 2D Symbologies | PDF417, MicroPDF417, QR Code, Micro QR, Data Matrix, Aztec |
| Wireless Communication | Bluetooth 5.0 (low energy) |
| Radio Range | Up to 40 m (open space) |
| Pairing | Directly in the host's Bluetooth settings, or with the Newland EasyConnect app (Android, iOS, Windows) by scanning the on-screen pairing barcode; optional NLS-DG-R Bluetooth USB dongle for PCs |
| Compatible Hosts | Android, iOS and Windows smartphones, tablets, mobile computers and PCs |
| Host Interfaces | Bluetooth HID keyboard (direct pairing); via NLS-DG-R dongle on Windows: keyboard, virtual COM (CDC) or HID POS; USB via the included magnetic cable: USB HID keyboard, USB CDC (virtual COM), HID POS |
| Batch Mode (Memory) | 1 MB flash – more than 16,000 EAN-13 codes |
| Wearing Style | Ring worn on the finger with adjustable strap; rotating scan head for left- or right-hand use; thumb-operated trigger |
| Battery | Rechargeable Li-ion, 4.35 V, 670 mAh (built in) |
| Operating Time | Up to 8 hours (depending on scanning intensity) |
| Charging Time | Less than 2 hours – via the included magnetic USB cable (5 V, 1 A) or the optional NLS-SCD20 charging cradle |
| Base Station | Not required and not included – optional 2-slot charging cradle NLS-SCD20 (charging only; up to 5 daisy-chained) |
| Reading Indicators | LED, beeper, vibration (good read, Bluetooth status, battery level) |
| Color | Black |
| Dimensions | 38 × 52.5 × 44.2 mm (W × L × H) |
| Weight | 48 g |
| Environmental Sealing | IP42 |
| Drop Resistance | 1.2 m |
| Electrostatic Discharge | ±12 kV (air discharge), ±8 kV (contact discharge) |
| Operating Temperature | −20 °C to 50 °C |
| Charging Temperature | 0 °C to 45 °C |
| Storage Temperature | −40 °C to 70 °C |
| Humidity | 5–95% RH, non-condensing |
| Software & Management | Newland EasySet configuration software; Newland EasyConnect pairing app |
| Certifications | CE, RoHS |
| Warranty | 36 months |
| In the Box | Newland WD4 ring scanner (2D imager, adjustable finger strap) with built-in rechargeable Li-ion battery (4.35 V, 670 mAh), magnetic USB cable (USB-A to magnetic connector – charging and wired USB) – charging cradle (NLS-SCD20), USB power adapter and Bluetooth dongle NOT included (optional); no base needed – pairs directly with phones, tablets and PCs via Bluetooth |
Compare the WD4 with other wireless models in our Cordless / Wireless Barcode Scanners collection, or contact our team for advice on a complete hands-free setup with charging cradles and volume pricing.
