BIXOLON XT3-40 Label Printer (XT3-43)

Regular price 779,44 € +VAT
Resolution (dpi)
203300

Free Shipping over 250 €. Usually delivered within 3–5 working days.

0% VAT for EU/EEA companies (excl. Estonia). Enter a valid VAT number to automatically generate a 0% VAT invoice.

BIXOLON XT3-43 industrial label printer, 2.4-inch colour LCD, tear-off, 300 dpi, thermal transfer (XT3-43) – front angled view
BIXOLON XT3-40 Label Printer (XT3-43)
Regular price 779,44 € +VAT

The BIXOLON XT3-43 is a compact 4-inch industrial thermal transfer label printer for warehouses, logistics, manufacturing and government. In a rugged all-metal case only 240 mm wide it prints 300 dpi labels at up to 152 mm/s (6 ips) with a print width of 105.7 mm, holds 203 mm label rolls and 450 m ribbons, and connects via USB, Ethernet, RS-232 and USB host as standard. This version, XT3-43, comes with: a tear-off bar for standard label printing. Power cord and USB cable are in the box.

📦 What's in the box – XT3-43

  • ✅ Printer – BIXOLON XT3-43 – 300 dpi – 2.4" colour LCD – Tear-off
  • ✅ Power supply – built in – plugs straight into the mains, no external power brick
  • ✅ Power cord – EU plug (Schuko), IEC C13 connector
  • ✅ USB cable – USB A to B – connect to your PC straight away
  • ❌ Serial (RS-232) cable – NOT included – optional – BIXOLON SER-KAB-9-9 (DB9, 1.8 m)
  • ❌ Ethernet (LAN) cable – NOT included – standard RJ45 patch cable, if you print over the network
  • ❌ Labels and ribbon – NOT included – please order matching media separately (see the compatible labels and ribbons on this page)
  • ✅ Quick installation guide – drivers, utilities and manuals are a free download from BIXOLON

💡 Ready to print out of the box: power cord and USB cable are included – just add labels and a ribbon.

💡 Useful extras: the BIXOLON SER-KAB-9-9 serial cable for RS-232 connections; BIXOLON cleaning pens (BIXOLON PCP-R200II/STD) for routine print head care; spare C13 power cords (JE39-00060A (EU), JE39-00064H (UK), SWISSPWRCRD (CH)).

Key Features

  • Industrial performance, compact footprint – up to 152 mm/s (6 ips) at 300 dpi, 105.7 mm print width and labels up to 2,000 mm long; thermal transfer and direct thermal printing.
  • Big media capacity – label rolls up to Ø 203 mm on 25.4–76.2 mm cores, media 20–114 mm wide incl. fanfold, and ribbons up to 450 m with ink inside or outside; side-loading media path for quick changes.
  • Rugged and easy to service – all-metal case with double-folding door, 2.4-inch colour LCD, toolless replacement of the print head and platen roller.
  • Connected as standard – USB 2.0, USB host, RS-232 and Ethernet on board; real-time clock; ENERGY STAR certified.
  • Works with your existing labels – SLCS™, BPL-Z™ (ZPL II compatible) and BPL-E™ (EPL compatible) emulations run existing formats without reprogramming.
  • Simple deployment – Twin function™ copies settings and data via USB stick; BIXOLON XPM™ / XCM™ management, SAP® device driver, Label Artist-II™ and BarTender® UltraLite.

Ideal Applications

  • Shipping, carton and pallet labels in logistics and e-commerce
  • Warehouse location, bin and inventory labels
  • Manufacturing – product, serial-number, GHS / chemical and compliance labels
  • Government and public sector – asset tags, archive and document labels
  • Print-and-apply workstations with the peeler / liner take-up versions

All XT3-40 / XT3-43 Versions

The highlighted row is the version you are currently viewing.

Part Number Resolution Media Handling Kit
XT3-40/BEG 203 dpi Tear-off Europe (EU cord) View product
XT3-40/MEA 203 dpi Tear-off Middle East & Africa View product
XT3-43 (this version) 300 dpi Tear-off Europe (EU cord) Viewing
XT3-409 203 dpi Peeler + liner take-up rewinder Europe (EU cord) View product
XT3-439 300 dpi Peeler + liner take-up rewinder Europe (EU cord) View product

Technical Specifications

Part Number XT3-43
Model BIXOLON XT3-43
Printer Type 4-inch industrial thermal transfer label printer
Print Method Thermal transfer and direct thermal
Resolution 300 dpi (12 dots/mm)
Print Speed Up to 152 mm/s (6 ips)
Max Print Width 105.7 mm
Label Length Up to 2,000 mm
Media Width 20–114 mm
Roll Diameter Max. 203 mm
Core Size 25.4–76.2 mm
Media Thickness 0.06–0.25 mm
Media Type Labels with gap, black mark or notch, continuous media, fanfold; thermal transfer and direct thermal
Sensors Transmissive (gap, adjustable), reflective (black mark, adjustable), ribbon end, head open
Ribbon Wax, wax/resin, resin – ink side outside or inside; width 40–110 mm; length up to 450 m; core 25.4 mm (1")
Media Options Tear-off – options across the series: peeler, auto-cutter, peeler + liner take-up rewinder (factory-fitted)
Interfaces USB 2.0 (Type B), USB host, RS-232 (DB9), Ethernet 10/100 Mbps
Wireless Not fitted in this version (WLAN / Bluetooth are factory options; dongles not supported)
Printer Languages SLCS™, BPL-Z™ (ZPL II compatible), BPL-E™ (EPL compatible)
Fonts / Character Sets Bitmap fonts: 10 SLCS™, 16 BPL-Z™, 5 BPL-E™; scalable fonts: 1 SLCS™, 1 BPL-Z™; 23 code pages; Unicode (UTF-8, UTF-16LE/BE); user-defined fonts, graphics, formats and logos
Barcodes 1D: Codabar, Code 11, Code 39, Code 93, Code 128, EAN-8, EAN-13, Industrial 2 of 5, Interleaved 2 of 5, Logmars, MSI, Plessey, Postnet, GS1 DataBar, Standard 2 of 5, UPC-A, UPC-E, UPC/EAN extensions, IMB; 2D: Aztec, Codablock, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code, TLC 39
Memory 128 MB SDRAM, 128 MB Flash
Display 2.4" colour TFT LCD with keys
Real-Time Clock Yes (standard)
Drivers & Software Windows driver (Europlus / Seagull), Linux / Mac CUPS driver, Virtual COM USB / Ethernet driver, OPOS / JPOS, SAP® device driver, Label Artist-II™, BarTender® UltraLite for BIXOLON, Network Auto Installer; SDKs for Android, iOS, Windows, Linux, Xamarin, Web Print
Device Management BIXOLON Profile Manager XPM™ / XCM™ (Windows, Android), Twin function™ (copy settings and data via USB memory)
Mobile Printing Label Artist™ Mobile and mPrint apps (Android, iOS)
Power Supply Built-in power supply, 100–240 V AC, 50/60 Hz (24 V DC, 4 A)
Housing All-metal case, double-folding door, side-loading media path
Dimensions (W × D × H) 240 × 430.5 × 276.7 mm
Weight 9.3 kg
Color Black
Operating Temperature 5 °C to 40 °C
Storage Temperature −20 °C to 60 °C
Humidity Operating 10–80% RH, storage 10–90% RH
Certifications ENERGY STAR
Warranty 24 months
In the Box BIXOLON XT3-43 printer (300 dpi, 2.4" colour TFT LCD with keys, tear-off, USB, USB host, RS-232, Ethernet), built-in power supply, power cord (EU plug, C13), USB cable, quick installation guide – labels and ribbon NOT included

Need more speed, 600 dpi or a touch display? The BIXOLON XT5-40 series is the high-end option on the same software platform. Compare other models in our Midrange Label Printers collection or contact our team for volume pricing.
