The BIXOLON SRP-Q200 is an ultra-compact 2-inch (58 mm) thermal receipt printer for small counters, cafés, food trucks, kiosks and ticketing where every centimetre counts. Its cube design measures just 103 × 104 × 109 mm and can be installed horizontally or vertically, yet it prints sharp 203 dpi receipts at up to 250 mm/s with an auto-cutter. This version, SRP-Q200EWDK, combines USB + Ethernet with dual-band Wi-Fi (2.4/5 GHz) for cable-free printing from POS PCs, tablets and smartphones; it comes with a power supply, an EU power cord and a starter roll – the USB cable is sold separately.
📦 What's in the box – SRP-Q200EWDK
- ✅ BIXOLON SRP-Q200 printer – black, USB + Ethernet + dual-band Wi-Fi, 203 dpi
- ✅ Power supply – external AC/DC power adapter (100–240 V AC)
- ✅ Power cord – EU plug (Schuko)
- ❌ USB cable – NOT included
- ❌ Ethernet (LAN) cable – NOT included
- ✅ Starter paper roll – 58 mm thermal paper to get you started
- ✅ Setup guide – drivers, utilities and manuals are a free download from BIXOLON
ℹ️ No USB cable is included. The printer works out of the box via Wi-Fi; for a wired USB connection please order the Bixolon USB-KAB-G USB cable (USB A to B) or use any standard USB 2.0 A-to-B printer cable. For a network connection, use a standard RJ45 Ethernet patch cable (not included).
💡 Useful extras: 58 mm thermal paper rolls (Zebra Z-Perform 1000D 60, 58 mm (3013689) or Zebra Z-Perform 1000D 80, 58 mm (3013690)); the Bixolon RBC-100 external buzzer or the Bixolon RMB-100G B-Melodist (sound + flashing light) – audible alerts for new orders in busy kitchens; a spare power supply (Bixolon SMPS-POS-4). The drawer kick-out port opens a cash drawer automatically with every sale – two drawers can be connected via a Y-type adapter.
Key Features
- Up to 250 mm/s at 203 dpi – fast, sharp receipts with logos and QR codes keep queues moving.
- Ultra-compact cube design – only 103 × 104 × 109 mm and 0.61 kg; fits the smallest counters and can be installed horizontally or vertically.
- Dual-band Wi-Fi + USB + Ethernet – 802.11a/b/g/n Wi-Fi (2.4/5 GHz) lets you place the printer wherever it is needed, with USB and Ethernet as wired alternatives.
- Easy drop-in paper loading – 58 mm rolls up to 60 mm in diameter, print width up to 54 mm and 36 characters per line (Font A).
- Reliable auto-cutter – rated for 1 million cuts, combined with a 100 km print head life.
- Mobile and web ready – SDKs for Android, iOS, Windows, Linux and Xamarin, a Chrome SDK, a Cordova plugin and the BIXOLON mPrint app for iOS.
- Practical set-up utility – the BIXOLON utility includes VMSM (virtual memory switch manager) and an NV image tool for storing your logo in the 768 KB NV memory.
- Cash drawers and order alerts – the drawer port drives up to two cash drawers (via a Y-type adapter); add an external buzzer or a B-Melodist for audible alerts.
- Broad driver support – BXL/POS command set with Windows, OPOS/JPOS, Linux/Mac CUPS and Virtual COM drivers for most POS software; ENERGY STAR certified.
Ideal Applications
- Small retail counters, boutiques and kiosks
- Cafés, bakeries, food trucks and quick-service restaurants
- Ticketing, queue management and parking
- mPOS and tablet POS set-ups
- Pharmacies, service desks and pop-up stores
All SRP-Q200 Versions
The highlighted row is the version you are currently viewing.
| Part Number | Interfaces | Wi-Fi | |
|---|---|---|---|
| SRP-Q200SK | USB + RS-232 | — | View product |
| SRP-Q200EWDK (this version) | USB + Ethernet | Wi-Fi 2.4/5 GHz | Viewing |
Technical Specifications
| Part Number | SRP-Q200EWDK |
|---|---|
| Model | BIXOLON SRP-Q200 |
| Printer Type | POS thermal receipt printer (single-station, ultra-compact 2-inch cube design) |
| Print Method | Direct thermal line printing |
| Resolution | 203 dpi (8 dots/mm) |
| Print Speed | Up to 250 mm/s |
| Paper Width | 58 mm; print width up to 54 mm |
| Characters per Line | Font A: 36, Font B/C: 48 (KOR/CHN/JPN: 18) |
| Roll Diameter | Max. 60 mm |
| Paper Thickness | 0.05–0.08 mm |
| Auto-cutter | Auto-cutter; life approx. 1 million cuts |
| Interfaces | USB 2.0 Full Speed (Type-B) + Ethernet (RJ45) + WLAN |
| Wireless | WLAN 802.11a/b/g/n dual-band (2.4/5 GHz) |
| Drawer Kick-out | Yes – drawer kick-out port; 2 drawers via Y-type adapter |
| Emulation / Command Set | BXL/POS |
| Fonts / Character Sets | Font A 12 × 24, Font B 9 × 17, Font C 9 × 24; KOR/CHN/JPN 24 × 24; 95 alphanumeric, 32 international character sets, 128 × 35 pages extended graphics; user-defined fonts, graphics and logos |
| Barcodes | 1D: Codabar, Code 39, Code 93, Code 128, EAN-8, EAN-13, ITF, UPC-A, UPC-E; 2D: Data Matrix, PDF417, QR Code |
| Drivers & Software | Windows driver, OPOS/JPOS, Linux/Mac CUPS, Virtual COM (USB/Ethernet) driver, utility program (VMSM, NV image tool) |
| Mobile Printing | Android/iOS/Windows SDK, Linux SDK, Xamarin SDK, Chrome SDK, Cordova plugin; mPrint app (iOS) |
| Memory | NV image memory 768 KB |
| Data Buffer | Receive buffer 4 KB; user-defined buffer 12 KB |
| Sensors | Paper end, cover open |
| Power Supply | External AC/DC power adapter (included); AC 100–240 V, 50/60 Hz |
| Installation | Horizontal or vertical |
| Dimensions (W × D × H) | 103 × 104 × 109 mm |
| Weight | 0.61 kg |
| Color | Black |
| Options | External buzzer (RBC-100), B-Melodist (RMB-100G), USB A-B cable 1.8 m |
| Operating Temperature | 0 °C to 40 °C |
| Storage Temperature | −20 °C to 60 °C |
| Humidity | 10–80% RH (operation); 10–90% RH (storage) |
| Print Head Life | 100 km |
| Certifications | ENERGY STAR certified |
| Warranty | 24 months |
| In the Box | BIXOLON SRP-Q200 printer (USB + Ethernet + dual-band Wi-Fi, 203 dpi, black), external AC/DC power adapter with EU (Schuko) power cord, 58 mm starter paper roll, quick start guide – USB cable and Ethernet cable NOT included (works via Wi-Fi without a cable; order a cable separately for wired use) |
Which version should you choose? Both SRP-Q200 versions share the same 203 dpi / 250 mm/s print engine, auto-cutter and compact housing: choose SK (USB + serial) for a wired connection to PCs and legacy POS systems, or EWDK (USB + Ethernet + dual-band Wi-Fi) for network and wireless printing. Need 80 mm receipts? See the BIXOLON SRP-Q300II. Compare other models in our POS Receipt Printers collection or contact our team for volume pricing.
Available Versions
SRP-Q200EWDK
Selected
Wired Interfaces
USB, Ethernet
receipt printer, direct thermal, resolution: 8 dots/mm (203 dpi), media width (max.): 58 mm, print width (max.): 54mm, roll diameter (max.): 60mm, speed (max.): 250 mm/s, connection: USB (type B), Ethernet, Wi-Fi (802.11a/b/g/n), drawer kickout, cutter, emulation: BXL/POS, incl.: power supply unit, power cable (EU), receipt roll, QSG, colour: black
159,52 €In Stock
SRP-Q200SK
Wired Interfaces
USB, RS232
receipt printer, direct thermal, resolution: 8 dots/mm (203 dpi), media width (max.): 58 mm, print width (max.): 54mm, roll diameter (max.): 60mm, speed (max.): 250 mm/s, connection: USB (type B), RS232 (9 pin), drawer kickout, cutter, emulation: BXL/POS, incl.: power supply unit, power cable (EU), receipt roll, QSG, colour: black
