Zebra ZQ620 Plus ir augstākās klases 3 collu mobilais printeris etiķetēm un čekiem – radīts plauktu un atlaižu etiķetēm, mobilajai tirdzniecības vietai, click & collect, noliktavas komplektēšanai un sūtījumiem. Tas drukā asas 203 dpi tiešās termodrukas etiķetes un čekus līdz 72 mm platumā ar ātrumu līdz 115 mm/s, tam ir liels krāsu displejs, IP54 aizsardzība un izturība pret 1,5 m kritieniem, un tas ir saderīgs ar QLn piederumiem. Šai versijai, ZQ62-AUFAE14-00, ir Bluetooth 4.2 (Classic + BLE), USB, RS-232 un NFC savienošana ar pieskārienu; komplektā ir 3250 mAh akumulators, jostas klipsis un plecu siksna – lādētājs jāiegādājas atsevišķi.
💡 Darba sākšanai varat apsvērt arī barošanas adapteri printera ZQ511 uzlādei, kā arī piemērotu čeku papīru vai etiķetes.
Iezīmētā rinda ir versija, kuru pašlaik skatāties.
| Daļas numurs | Savienojamība | Materiāla veids | Akumulators | |
|---|---|---|---|---|
| ZQ62-AUXAE14-00 | Wi-Fi 6 + BT 5.3 | Standarta | 3250 mAh | Skatīt produktu |
| ZQ62-AUWAE14-00 | Wi-Fi 5 + BT 4.2 | Standarta | 3250 mAh | Skatīt produktu |
| ZQ62-AUFAE14-00 (šī versija) | Bluetooth 4.2 | Standarta | 3250 mAh | Skatāt |
| ZQ62-AUX2E14-00 | Wi-Fi 6 + BT 5.3 | Bezpamatnes | 3250 mAh | Skatīt produktu |
| ZQ62-AUWBE14-00 | Wi-Fi 5 + BT 4.2 | Bezpamatnes | 3250 mAh | Skatīt produktu |
| ZQ62-AUXAEC4-00 | Wi-Fi 6 + BT 5.3 | Standarta | 6500 mAh | Skatīt produktu |
| Daļas numurs | ZQ62-AUFAE14-00 |
|---|---|
| Modelis | Zebra ZQ620 Plus (ZQ600 Plus Series) |
| Printera tips | Mobile label and receipt printer, 3-inch |
| Drukas metode | Direct thermal |
| Izšķirtspēja | 203 dpi (8 dots/mm) |
| Drukas ātrums | Up to 115 mm/s (4.5 in/s) |
| Drukas platums | 72 mm (2.8 in) |
| Materiāla platums | 25 mm to 79 mm (1.0–3.125 in) |
| Ruļļa diametrs | Max. 66 mm (2.6 in) OD on 19 mm (0.75 in) or 34.9 mm (1.375 in) core |
| Papīra biezums | 0.058–0.140 mm tag stock or up to 0.165 mm label stock (2.3–5.5 mil tag, 6.5 mil label); label length 12.7–813 mm |
| Materiāla veids | Die-cut labels and tags, receipt paper, black-mark and gap media |
| Sensori | Black mark and gap (fixed centre position); label present sensor for peel-and-present |
| Interfeisi | USB 2.0 full-speed (Mini-B connector, optional strain relief); 14-pin RS-232C serial up to 115.2 kbps; 10/100 Ethernet via optional charging cradle |
| Bezvadu savienojums | Bluetooth 4.2 (Classic + BLE), security modes 1–4, MFi certified – no Wi-Fi |
| NFC | Zebra Print Touch – NFC tap-to-pair and web help pages |
| Emulācija / komandu kopa | CPCL, EPL, ZPL, ZBI 2.x, XML; Link-OS |
| Fonti / rakstzīmju kopas | 25 bitmapped + 1 smooth scalable font (CG Triumvirate Bold Condensed); optional downloadable fonts and Chinese, Japanese, Korean, Thai, Vietnamese character sets |
| Svītrkodi | 1D: Code 39, Code 93, UCC/EAN-128, Code 128, Codabar (NW-7), Interleaved 2 of 5, UPC-A, UPC-E, EAN-8, EAN-13 (2/5-digit add-ons), GS1 DataBar, MSI/Plessey, Postnet; 2D: PDF417, MicroPDF417, MaxiCode, QR Code, Data Matrix, Aztec, TLC39 |
| Atmiņa | 256 MB RAM / 512 MB Flash (128 MB user available) |
| Displejs | Large colour display (288 × 240 pixels), 5-way navigation, 2 soft keys, colour alerts |
| Draiveri un programmatūra | Zebra Print DNA, Link-OS, Printer Setup Utilities, Printer Profile Manager Enterprise, PrintSecure; AirWatch, SOTI MobiControl, Ivanti Avalanche |
| Mobilā drukāšana | Android, Apple iOS (MFi), Windows |
| Akumulators | 3250 mAh (23.4 Wh) PowerPrecision+ Li-ion, removable (BTRY-MPP-34MA1-01) – included; optional extended-capacity battery |
| Uzlāde | Built-in charger – via AC adapter (P1031365-042 EU / P1031365-041 UK) or single / 4-slot Ethernet charging cradle; spare batteries in 1-, 3- or 6-slot chargers – all sold separately |
| Aizsardzības klase | IP54 |
| Izturība pret kritieniem | Multiple 1.52 m (5 ft) drops to concrete |
| Izmēri (P × Dz × A) | 117.9 × 173.7 × 76.9 mm (W × L × H) |
| Svars | 0.73 kg with battery |
| Krāsa | Black |
| Darba temperatūra | −20 °C to 50 °C |
| Uzglabāšanas temperatūra | −25 °C to 65 °C |
| Mitrums | 10–90% non-condensing |
| Sertifikāti | FCC Part 15 Subpart B, EN 55022 Class B, EN 60950, EN 55024, EN 61000-4-2/3/4/5, VCCI Class B; CE, TÜV, CSA; ENERGY STAR; FIPS support available |
| Garantija | 12 months |
| Iepakojuma saturs | Zebra ZQ620 Plus printer (Bluetooth 4.2, USB, RS-232, NFC, black), 3250 mAh PowerPrecision+ Li-ion battery (BTRY-MPP-34MA1-01), belt clip (fitted), shoulder strap, quick start guide |
Kuru versiju izvēlēties? AUX versijām ir jaunākais Wi-Fi 6 + Bluetooth 5.3 radio, AUW versijām – Wi-Fi 5 + Bluetooth 4.2, bet AUF ir tikai ar Bluetooth. Izvēlieties bezpamatnes (linerless) versiju (AUX2 / AUWB) etiķetēm bez pamatnes vai …EC4 ar paplašinātas ietilpības akumulatoru. Slimnīcām un klīnikām skatiet dezinfekcijai piemēroto Zebra ZQ620 Plus Healthcare. Salīdziniet citus modeļus mūsu kolekcijā Mobilie čeku printeri vai sazinieties ar mūsu komandu, lai saņemtu cenas lielākiem apjomiem.
| Part Number | Wireless | Linerless | In the Box | Price | ||
|---|---|---|---|---|---|---|
 |
ZQ62-AUFAE14-00Viewing | Bluetooth 4.2 | No | + battery (3250 mAh) | 827,54 €+PVNNoliktavā | |
 |
ZQ62-AUWAE14-00 | Bluetooth 4.2 + Wi-Fi 5 | No | + battery (3250 mAh) | 866,42 €+PVNNav noliktavā | View |
 |
ZQ62-AUWBE14-00 | Bluetooth 4.2 + Wi-Fi 5 | Yes | + battery (3250 mAh) | 897,34 €+PVNNav noliktavā | View |
 |
ZQ62-AUX2E14-00 | Bluetooth 5.3 + Wi-Fi 6 | Yes | + battery (3250 mAh) | 970,47 €+PVNNoliktavā | |
 |
ZQ62-AUXAE14-00 | Bluetooth 5.3 + Wi-Fi 6 | No | + battery (3250 mAh) | 937,03 €+PVNNoliktavā | |
 |
ZQ62-AUXAEC4-00 | Bluetooth 5.3 + Wi-Fi 6 | No | + extended battery (6500 mAh) | 995,55 €+PVNNoliktavā |
| Product | Size (W × H) | Material | Labels / roll | Core | Price | ||
|---|---|---|---|---|---|---|---|
 |
Zebra PolyPro 4000D3003355 | 76.2 × 25.4 mm | Synthetic | 500 | 19 mm | 15,05 €+PVNNav noliktavā | View |
 |
Zebra Z-Select 2000D3002086 | 76.2 × 101.6 mm | Thermal Paper | 130 | 35 mm | 7,90 €+PVNNav noliktavā | View |
 |
Zebra Z-Select 2000D3002087 | 76.2 × 76.2 mm | Thermal Paper | 170 | 35 mm | 7,90 €+PVNNoliktavā | |
 |
Zebra Z-Perform 1000D 110 Tag3003349 | 76.2 × 38.1 mm | Thermal Paper | 400 | 35 mm | 10,81 €+PVNNav noliktavā | View |
 |
Zebra Z-Select 2000D Removable3004840-T | 76.2 × 44.45 mm | Thermal Paper | 350 | 19 mm | 11,37 €+PVNNoliktavā | |
 |
Zebra Z-Perform 1000D3012911-T | 76.2 × 50.8 mm | Thermal Paper | 187 | 19 mm | 3,98 €+PVNNav noliktavā | View |
 |
Zebra Z-Perform 1000D3013759 | 76.2 × 50.8 mm | Thermal Paper | 96 | 19 mm | 3,67 €+PVNNoliktavā | |
 |
Zebra ZeroLiner 2000DZIPZLM3016410 | 76 × 19000 mm | Thermal Paper | 1 | 19 mm | 9,80 €+PVNNav noliktavā | View |
 |
Tsc W: 75 mm38-T075050-14LF | 75 × 50 mm | Thermal Paper | 300 | 19 mm | 2,65 €+PVNNav noliktavā | View |
 |
Zebra ZeroLiner 2000DZIPZLM3013255 | 58 × 100000 mm | Thermal Paper | 1 | 12.7 mm | 7,92 €+PVNNav noliktavā | View |
 |
Tsc W: 58 mm38-T058075-14LF | 58 × 75 mm | Thermal Paper | 180 | 19 mm | 2,04 €+PVNNav noliktavā | View |
 |
Tsc W: 55 mm38-T055070-14LF | 55 × 70 mm | Thermal Paper | 200 | 19 mm | 2,07 €+PVNNav noliktavā | View |
 |
Zebra Z-Perform 1000D3013758 | 54.5 × 38.1 mm | Thermal Paper | — | 19 mm | 3,37 €+PVNNav noliktavā | View |
 |
Zebra PolyPro 4000D3003347 | 50.8 × 25.4 mm | Synthetic | 340 | 19 mm | 8,54 €+PVNNoliktavā | |
 |
Zebra PolyPro 4000D3006404-T | 50.8 × 50.8 mm | Synthetic | 200 | 19 mm | 8,09 €+PVNNav noliktavā | View |
 |
Zebra Z-Perform 1000D3012910-T | 50.8 × 25.4 mm | Thermal Paper | 353 | 19 mm | 3,12 €+PVNNoliktavā | |
 |
Zebra Z-Perform 1000D3007842-T | 50.8 × 25.4 mm | Thermal Paper | 430 | 19 mm | 3,70 €+PVNNoliktavā | |
 |
Zebra Z-Select 2000D3014816-T | 50.8 × 25.4 mm | Thermal Paper | 446 | 19 mm | 5,78 €+PVNNav noliktavā | View |
 |
Zebra ZeroLiner 2000DZIPZLM3017704 | 50.8 × 19000 mm | Thermal Paper | 1 | 19 mm | 6,79 €+PVNNav noliktavā | View |
 |
Tsc W: 50 mm38-T050020-14LF | 50 × 20 mm | Thermal Paper | 650 | 19 mm | 2,20 €+PVNNav noliktavā | View |
 |
Tsc W: 50 mm38-T050035-14LF | 50 × 35 mm | Thermal Paper | 400 | 19 mm | 1,96 €+PVNNav noliktavā | View |
 |
Tsc W: 50 mm38-T050050-14LF | 50 × 50 mm | Thermal Paper | 300 | 19 mm | 2,11 €+PVNNav noliktavā | View |
 |
Tsc W: 47 mm38-T047047-14LF | 47 × 47 mm | Thermal Paper | 300 | 19 mm | 1,89 €+PVNNav noliktavā | View |
 |
Tsc W: 45 mm38-T045030-14LF | 45 × 30 mm | Thermal Paper | 450 | 19 mm | 2,06 €+PVNNav noliktavā | View |
 |
Tsc W: 40 mm38-T040040-14LF | 40 × 40 mm | Thermal Paper | 350 | 19 mm | 1,60 €+PVNNav noliktavā | View |
 |
Zebra Z-Perform 1000D3008872-T | 38.1 × 38.1 mm | Thermal Paper | 270 | 19 mm | 4,49 €+PVNNav noliktavā | View |
 |
Tsc W: 32 mm38-T032020-14LF | 32 × 20 mm | Thermal Paper | 650 | 19 mm | 1,67 €+PVNNav noliktavā | View |
